FEATURES SUMMARY
■ 5V ± 10% SUPPLY VOLTAGE in READ OPERATION
■ ACCESS TIME: 45ns
■ LOW POWER “CMOS” CONSUMPTION:
– Active Current 30mA
– Standby Current 100µA
■ PROGRAMMING VOLTAGE: 12.75V ± 0.25V
■ PROGRAMMING TIMES of AROUND 6sec.
■ ELECTRONIC SIGNATURE
– Manufacturer Code: 20h
– Device Code: 3Dh
■ PACKAGES
– Lead-Free Versions
DC AND AC PARAMETERS
This section summarizes the operating and measurement conditions, and the DC and AC characteristics of the device. The parameters in the DC and AC Characteristic tables that follow are derived from tests performed under the Measurement Conditions summarized in the relevant tables. Designers should check that the operating conditions in their circuit match the measurement conditions when relying on the quoted parameters
Vous pouvez télécharger la fiche technique dessous :
Cliquez ici
