AVC63-7AVR REGULATEUR DE TENSION AUTOMATIQUE

DC Output Power
7 Adc at 63 Vdc maximum continuous with a 240 Vac input.
Exciter Field DC Resistance
9.0 ohms minimum.
AC Power Input
170 to 305 Vac, single-phase, 50/60 Hz.
Burden: 900 VA maximum at 240 Vac power.
AC Sensing Voltage
170 to 264 Vac, single-phase, 50/60 Hz.
Burden: 5 VA.
Voltage Adjust Range
170 to 264 Vac using the internal voltage adjust. The
external voltage adjust provides a ±10% adjustment of the
nominal value determined by the internal voltage adjust.
Regulation Accuracy
±0.25%
Voltage Drift
<±1% voltage variation for a 50°C (122°F) change.
Response Time
<16 ms
Frequency Compensation
Refer to Figure 1.
Voltage Buildup
Internal provisions for automatic buildup from generator
residual voltage as low as 6 Vac at 25 Hz.
Power Dissipation
35 W maximum
Paralleling Provisions
CT input for customer supplied 5 A nominal CT. Adjustable
droop from 0 to 6% with 5 A input at 0.8 power factor. CT
input burden is 2.5 VA.
