UTD2102CL+ OSCILLOSCOPE NUMERIQUE 2X100 MHZ

• 100 MHz analog bandwidth and two analog channel inputs
• Maximum real-time sample rate of 500 MSa/s
• Maximum memory depth of 64k points
• Maximum waveform capture rate of 5000 wfms/s
• Vertical scale: 1 mV/div to 20 V/div
• Math function for Complex Calculations: Simplify complex waveform analysis with the Uni-T UTD2102CL+ Digital Storage Oscilloscope
• Zoom function for In-Depth Analysis: Examine waveforms at various levels of detail
• The XY mode (Lissajous graphics mode) is a highlight, offering quick and accurate measurement of phase differences between signals
• With the simple press of the AUTO button, the Uni-T UTD2102CL+ Digital Storage Oscilloscope automatically adjusts the vertical scale, horizontal time base, and trigger mode based on input signals.
• The Uni-T UTD2102CL+ Digital Storage Oscilloscope excels in FFT spectral analysis, converting time-domain signals into their frequency-domain elements
• Automatic measurement of 34 waveform parameters
• Interface: USB device, Pass Test Output (BNC)
• 7″ (17.8 cm) screen, 800×480
• Certifications: cETLus, CE, RoHS, UKCA

Applications

• Classroom education
• Repair and maintenance
