Multi-turn potentiometer WXD3-13-2W
Reference: AM1302
EAN13: –
Product attributes:
Resistance: 100 Ohm, 100R, 200 Ohm, 200R, 220 Ohm, 220R, 680
Ohm, 680R, 1 kOhm, 1K0, 2.2 kOhm, 2K2, 3.3 kOhm, 3K3, 4.7
kOhm, 4K7, 5.6 kOhm, 5K6, 6.8 kOhm, 6K8, 10 kOhm, 10K, 22
kOhm, 22K, 33 kOhm, 33K, 47 kOhm, 47K, 100 kOhm, 100K, 68
kOhm, 68K, 470 Ohm, 470R
Product features:
Resistance: 10 kOhm
Tolerance: 5%
Number of pins: 3-pin
Product description:
Multi-turn potentiometer with 1 kOhm resistance and ±5% tolerance .
Maximum voltage: 160 V DC
Pd – Power dissipation: 2 W
Number of turns: 10 (3600°)
Dimensions: 38 x 21mm
Shaft length: 11mm, shaft diameter: 4mm
